CPU i3 540





CPU i3 540



Product Description
Status Launched
Launch Date Q1'10
Processor Number i3-540
# of Cores 2
# of Threads 4
Clock Speed 3.06 GHz
Intel® Smart Cache 4 MB
DMI 2.5 GT/s
Instruction Set 64-bit
Instruction Set Extensions SSE4.2
Embedded Options Available

 Yes
Lithography 32 nm
Max TDP 73 W
VID Voltage Range 0.6500V-1.4000V
Recommended Customer Price





Graphics Specifications
Processor Graphics ‡ Intel® HD Graphics
Graphics Base Frequency 733 MHz
Intel® Flexible Display Interface (Intel® FDI) Yes
Intel® Clear Video HD Technology Yes
# of Displays Supported ‡ 2
Expansion Options
PCI Express Revision 2.0
PCI Express Configurations ‡ 1x16, 2x8
Max # of PCI Express Lanes 16



Max CPU Configuration 1
TCASE 72.6°C
Package Size 37.5mm x 37.5mm
Processing Die Size 81 mm2
# of Processing Die Transistors 382 million
Graphics and IMC Lithography 45 nm
Graphics and IMC Die Size 114 mm2
# of Graphics and IMC Die Transistors 177 million
Sockets Supported FCLGA1156
Low Halogen Options Available See MDDS
